Panasonic AG-AC160P

Panasonic AG-AC160P


Panasonic's AG-AC30 Full HD Camcorder with Touch Panel LCD Viewscreen and Built-In LED Light is at home shooting corporate, event, and indie projects. It features a 1/3.1" BSI MOS sensor for improved low-light performance and incorporates a 20x zoom lens with 5-axis hybrid image stabilization. The lens also features electronically linked geared iris rings for manual control of focus, zoom, and iris. Built-into the top handle is an LED light for illuminating your subject in dim light.

Two viewfinders provide you a choice when operating the camera with either a traditional tilt up color EVF, or a pull out LCD high resolution touchscreen. The LCD touchscreen is positioned above the lens for a more natural viewing experience when shooting handheld. Slow motion recording functionality is included, allowing you to record in Full HD up to 120 fps. The camera records in MP4, MOV, or AVCHD codecs, and features dual SDXC media card slots. allowing you to use relay recording or simultaneous recording.


Illumination Approx. 300 lux @ 3.3' / 1.0 m
Approx. 70 lux (with diffusion)
Beam Angle Approx. 30
Color Temperature Native: Approx. 5000K
With Conversion Filter: Approx. 3000K
Sensor 1/3.1" BSI MOS Sensor
Effective Pixels 6.03 MP (16:9)
Focal Length 4.08 - 81.6 mm
35mm Equivalent Focal Length 29.5 to 612mm (16:9)
Maximum Aperture f/1.8 - f/3.6
Zoom Optical: 20x
Intelligent: 40x (in HD)
Digital: 2x, 5x, 10x
Filter Size 49 mm
System NTSC
Recording Media SDHC/SDXC
Still Image Resolution JPEG
1920 x 1080: 2.1 MP
640 x 360: 0.2 MP
640 x 480: 0.3 MP
Channels 2
Audio Format AAC
Dolby Digital 2-ch
Type 3.0" / 7.6 cm touchscreen LCD
460,000 pixel count
270 rotation

0.24" / 0.61 cm Viewfinder
1,555,000 pixel count
Exposure Control
Shutter Speed 60p / 60i: 1/8 - 1/8000 23.98p: 1/6 - 1/8000 Super Slow: 1/120 - 1/8000
Image Stabilization 5-Axis hybrid O.I.S.
Lux 1400
1.4 (Super Gain 30 dB, Shutter 1/30)
Built-in Mic Yes
Built-in Speaker Yes
Accessory Shoe 1 x cold shoe
Tripod Mount 1/4" - 20
Input/Output Connectors
Inputs 2 x XLR microphone
1 x 1/8" (3.5 mm) mini jack (Zoom S/S)
1 x 2.5 mm super mini jack (Focus/Iris)
Outputs 1 x A/V
1 x HDMI A (Full Size)
1 x USB 3.0 Type A (Host)
1 x USB Micro-B USB 3.0
Microphone Input Yes
Headphone Jack Yes
Battery Rechargeable Lithium-Ion Battery Pack, 7.2 VDC
Charging Method AC Adapter
Dimensions 6.7 x 6.7 x 13.2" / 17.0 x 17.0 x 33.5 cm
Weight 3.31 lb / 1.5 kg (without battery or SD card)

Package Items

1x Panasonic AG-AC160P
